ReactJS inline styles VS CSS : benchmark

Aug 17th, 2015

4 min read

I was wondering what are the performance downsides when we are using ReactJS (it’s the same for any other framework) with inline styles only, against using external CSS stylesheets.

We know that the size of inline styles can be huge (especially if we repeat elements). This is exactly the situation we are going to test here. This way, we can test browser performance when it comes to parse, save, and apply a bunch of inlines styles, against a unique CSS stylesheet.


Summary


When use one against the other?

I think both ways are useful and have a specific area of application.

As Michael Chan said at React Europe (video):

  • CSS stylesheets can be used for the layout: such as the bootstrap layout classes: row-fluid, span*. They are fixed and form the static part of the website.
  • The inline styles should be used for the state-styles: the style that can change according to a state. They form the dynamic part of the website.

It’s not relevant

I decided to try something stupid and not truly relevant to a real business case:

  • Generate two big <table>s: one with inline styles, one with CSS stylesheets. Same content.
  • Check the performance/smoothness/size/time of rendering for both.

It’s not relevant because we would not generate a big table in our DOM. We should have some kind of virtual scrolling/lazy rendering.

But, what about a harmless test, just to check if that’s more slow when I scroll or not, and what about the rendering times ?

Chrome 45b, React 0.13.3

The experience

So we generate a <table> of 1,000 rows with 9 columns. All of them with the same content my.email@example.com. We do the same with 10,000 rows to check the “trend”.

We’re going to test :

  • The smoothness when I scroll down the page through Chrome DevTools Timeline.
  • The size of the DOM: it’s useful to know for isomorphic universal Javascript application (server-side rendering).
  • The time to mount the DOM: I’m going to use componentDidMount: this is where the DOM is available after render is called.
  • The time to be rendered: I’m going to use requestAnimationFrame to know when the next frame after render is ready.

The skeleton of the ReactJS component is :

const createOneInlineStyleRow = (i) => <tr key={i}>
                                        <td style={style}>my.email@example.com</td>
                                        ...repeat...
                                       </tr>

export default class AppInline extends React.Component {
    componentDidMount() {
        console.timeEnd('didMount')
    }
    render() {
        console.time('render');
        console.time('didMount');
        requestAnimationFrame(function() { console.timeEnd('render'); })

        const rows = times(NB_ROWS, createOneInlineStyleRow)
        return <table style={TABLE_STYLE}><tbody>{rows}</tbody></table>
    }
}

Some random style for the <td>:

const style = {
    fontFamily: 'Consolas',
    padding: 10,
    color: "#444",
    border: "3px solid orange",
    position: "relative",
    width: "15%",
    height: "25px",
    letterSpacing: 0,
    overflow: "hidden",
    fontSize: 10,
    fontVariant: "small-caps"
}

And the same in CSS for the stylesheet:

.tableCss td {
    font-family: Consolas;
    padding: 10px;
    color: #444;
    border: none;
    border: 3px solid orange;
    position: relative;
    width: 15%; height: 25px;
    letter-spacing: 0;
    overflow: hidden;
    font-size: 10px;
    font-variant: small-caps;
}

Basically, here is this beautiful design :

Results

Timeline

I found no difference when scrolling.

Chrome DevTools timeline supports my perception: no difference, no fps drop.

The fact that the DOM is inline or in an external CSS stylesheet does not matter. I guess it’s already in the browser memory when it’s rendered so it does not influence the smoothness.

Size of the DOM

No surprise: the DOM size is huge with the inline styles and is linearly proportional to the number of rows.

Type 1,000 rows 10,000 rows Ratio
CSS 517,725 chars ~5,177,250 chars x10
Inline 2,283,742 chars ~22,837,420 chars x10
x4.4 x4.4

That’s clearly something to take into account if you do some universal javascript. 2,000,000 chars is 2MB of data. (but who sends a big table anyway?!)

As calebwright pointed out in the comments, over the network, we are generally gzipping the content. Without random content in the table, the 2MB DOM compresses to 200k.

Also, as Daniel Meneses said, with SSR, the inline styles will be downloaded each and every time (part of the HTML), whereas a CSS stylesheet will be downloaded once. (thanks to the browser’s cache)

Time to mount the DOM

We start a timer in the render method and end it when componentDidMount is called.

React has done its job converting the virtual DOM into DOM and has injected it into our mounted node.

I let the times with the development version of React, because I started with and used the production version afterwards. They should not be taken into account, it’s not relevant in our case.

Type 1,000 rows 10,000 rows Ratio
CSS (debug) 650ms-750ms 6,000ms ~x10
Inline (debug) 1,000ms-1100ms 10,000ms ~x10
CSS 310ms 2,300ms ~x7.5
Inline 600ms 4,900ms ~x8
x2 x2.1

It takes twice the time to convert our virtual DOM with inline styles to DOM and mount it.

The delta decreases with less rows but it’s still significant: 70ms (css) against 105ms (inline) for 100 rows (x1.5).

Rendering time

The DOM is mounted, the browser needs to render the table.

We assume it will take longer to render the inline styles, because it has more to parse and store every style attribute of every td.

Type 1,000 rows 10,000 rows Ratio
CSS (debug) 1,100ms-1,200ms 9,500ms ~x10
Inline (debug) 1,500-1,600ms 14,000ms ~x10
CSS 720ms 6,000ms ~x8
Inline 1,080ms 9,400ms ~x8.7
x1.5 x1.56

There is still a small overhead.

I guess those performances are quite browser-dependent.

What about another browser ? Let’s try with Edge.

I gave a try on Edge with 10,000 rows:

Type mount time rendering time
CSS 4,115ms 11,591ms
Inline 11,418ms 21,113ms
x2.7 x1.8

The numbers are the double of Chrome’s numbers. :cry:

Conclusion

That was the expected behavior. At least, we have some numbers now.

Inline styles take way more size in the DOM, are converted more slowly from VDOM (have probably a bigger impact on memory), and take more time to be handled by the browser.

But they have no impact on performance once it’s rendered.
